MongoDB Kanister Hooks for KubeVirt VMs on OpenShift

This document covers the setup of Kasten K10 pre/post backup hooks for a MongoDB instance running inside a KubeVirt VM on OpenShift. The hooks use a Kanister Blueprint to issue fsyncLock and fsyncUnlock commands around the Kasten snapshot, ensuring crash-consistent backups.

GitHub - jdtate101/kubevirt-kanister-bp: Example blueprint for mongodb running inside a rhel10 VM on OVE

Example blueprint for mongodb running inside a rhel10 VM on OVE - jdtate101/kubevirt-kanister-bp

GitHubjdtate101

Architecture

Kasten K10 (kasten-io)
    │
    ├── backupPrehook  ──► KubeTask Pod ──► mongo-kanister ClusterIP SVC ──► virt-launcher pod ──► RHEL VM ──► mongod
    │
    └── backupPosthook ──► KubeTask Pod ──► mongo-kanister ClusterIP SVC ──► virt-launcher pod ──► RHEL VM ──► mongod

Rather than exec-ing into the VM (which is not possible with KubeVirt), the blueprint spawns a throwaway kanisterio/mongodb pod that connects to MongoDB over the network via a ClusterIP service. The service selects the virt-launcher pod using the vm.kubevirt.io/name label.

Prerequisites

• OpenShift with KubeVirt/OpenShift Virtualization installed
• Kasten K10 installed in the kasten-io namespace
• A RHEL VM running MongoDB, exposed via a ClusterIP service
• MongoDB configured with authentication enabled and listening on 0.0.0.0:27017

Components

MongoDB Installation (RHEL 10)

1. Add the MongoDB repository

cat > /etc/yum.repos.d/mongodb-org-8.0.repo << 'EOF'
[mongodb-org-8.0]
name=MongoDB Repository
baseurl=https://repo.mongodb.org/yum/redhat/9/mongodb-org/8.0/x86_64/
gpgcheck=1
enabled=1
gpgkey=https://pgp.mongodb.com/server-8.0.asc
EOF

Note: RHEL 10 is not yet in MongoDB's official repo matrix. The RHEL 9 baseurl is compatible.

2. Install and start MongoDB

dnf install -y mongodb-org
systemctl enable --now mongod

3. Configure mongod.conf

Edit /etc/mongod.conf to bind on all interfaces and enable auth:

net:
  port: 27017
  bindIp: 0.0.0.0

security:
  authorization: enabled

4. Create the root user

With auth enabled but no users yet, MongoDB allows a one-time unauthenticated connection from localhost (the localhost exception):

mongosh admin --eval "
db.createUser({
  user: 'root',
  pwd: 'YOUR_PASSWORD',
  roles: [ { role: 'root', db: 'admin' } ]
})
"

5. Restart and verify

systemctl restart mongod

mongosh --authenticationDatabase admin -u root -p YOUR_PASSWORD \
  --eval "db.runCommand({ connectionStatus: 1 })"

Expected output includes "authenticated" : true.

Kubernetes Resources

Secret

Stores the MongoDB root password. Must be in the same namespace as the VM.

apiVersion: v1
kind: Secret
metadata:
  name: mongo-kanister
  namespace: <VM namespace>
type: Opaque
stringData:
  mongodb-root-password: "YOUR_PASSWORD"

Warning: Do not commit this file to source control with a plaintext password. Use Sealed Secrets, Vault, or equivalent.

ClusterIP Service

Exposes the MongoDB port from the virt-launcher pod. The selector uses vm.kubevirt.io/name which KubeVirt automatically applies to the virt-launcher pod.

apiVersion: v1
kind: Service
metadata:
  name: mongo-kanister
  namespace: <VM namespace>
spec:
  selector:
    vm.kubevirt.io/name: <VM name>
  ports:
  - name: mongodb
    protocol: TCP
    port: 27017
    targetPort: 27017
  type: ClusterIP

Verify the endpoint is populated after applying:

oc get endpoints mongo-kanister -n <VM namespace>

You should see a pod IP listed under ENDPOINTS. If it shows <none>, the selector is not matching — check the virt-launcher pod labels:

oc get pods -n <VM namespace>--show-labels | grep virt-launcher

Kanister Blueprint

The blueprint runs in kasten-io and spawns a KubeTask pod in the VM namespace for each hook phase.

actions:
  backupPrehook:
    kind: ""
    name: ""
    phases:
    - args:
        command:
        - bash
        - -o
        - errexit
        - -o
        - pipefail
        - -c
        - |
          export MONGODB_ROOT_PASSWORD='{{ index .Phases.lockMongo.Secrets.mongoDbSecret.Data "mongodb-root-password" | toString }}'
          mongosh --authenticationDatabase admin \
            -u root \
            -p "${MONGODB_ROOT_PASSWORD}" \
            --host mongo-kanister.{{ .Object.metadata.namespace }}.svc.cluster.local \
            --eval "db.fsyncLock()"
        image: ghcr.io/kanisterio/mongodb:0.116.0
        namespace: '{{ .Object.metadata.namespace }}'
      func: KubeTask
      name: lockMongo
      objects:
        mongoDbSecret:
          apiVersion: ""
          group: ""
          kind: Secret
          name: mongo-kanister
          namespace: '{{ .Object.metadata.namespace }}'
          resource: ""
  backupPosthook:
    kind: ""
    name: ""
    phases:
    - args:
        command:
        - bash
        - -o
        - errexit
        - -o
        - pipefail
        - -c
        - |
          export MONGODB_ROOT_PASSWORD='{{ index .Phases.unlockMongo.Secrets.mongoDbSecret.Data "mongodb-root-password" | toString }}'
          mongosh --authenticationDatabase admin \
            -u root \
            -p "${MONGODB_ROOT_PASSWORD}" \
            --host mongo-kanister.{{ .Object.metadata.namespace }}.svc.cluster.local \
            --eval "db.fsyncUnlock()"
        image: ghcr.io/kanisterio/mongodb:0.116.0
        namespace: '{{ .Object.metadata.namespace }}'
      func: KubeTask
      name: unlockMongo
      objects:
        mongoDbSecret:
          apiVersion: ""
          group: ""
          kind: Secret
          name: mongo-kanister
          namespace: '{{ .Object.metadata.namespace }}'
          resource: ""
apiVersion: cr.kanister.io/v1alpha1
kind: Blueprint
metadata:
  name: mongo-vm-hooks
  namespace: kasten-io

VM Annotation

Annotate the VirtualMachine object so Kasten picks up the blueprint automatically:

oc annotate virtualmachine <VM name> -n <VM namespace> \
  kanister.kasten.io/blueprint='mongo-vm-hooks'

Or add it directly to the VM manifest:

metadata:
  name: <VM name>
  namespace: <VM namespace>
  annotations:
    kanister.kasten.io/blueprint: mongo-vm-hooks

Connectivity Test

Before running the policy, verify the kanister job pod can reach MongoDB across the service:

oc run mongo-test -n <VM namespace> --rm -it \
  --image=ghcr.io/kanisterio/mongodb:0.116.0 -- \
  mongosh --host mongo-kanister.<VM namespace>.svc.cluster.local \
  --authenticationDatabase admin -u root -p YOUR_PASSWORD \
  --eval "db.runCommand({ connectionStatus: 1 })"

Troubleshooting
